Scroll compressors with internal line break overload and highpressure protection
-
Single stage compressor on B072 and B085 models
-
Two stage compressor on B090 – B150 models
-
Convertible airflow
-
TXV refrigerant metering system on each circuit (except on B072 and B085)
-
High Pressure and Low Pressure/Loss of charge protection standard on all models
-
Solid Core liquid line filter drier on each circuit
-
Single slab, single pass designed evaporator and condenser coils facilitate easy cleaning for maintained high efficiencies
-
Cooling operation up to 125 degree F ambient
-
Foil faced insulation encapsulated throughout entire unit minimizes airborne fibers from the air stream
-
Hinged major access door with heavy-duty gasketing, 1/4 turn latches and door retainers
-
Slide Out Indoor fan assembly for added service convenience
-
Powder Paint Finish meets ASTMB117 steel coated on each side for maximum protection. G90 galvanized
-
One piece top cover and one piece base pan with drawn supply and return opening for superior water management
-
Forkable base rails for easy handling and lifting
-
Single point electrical connections
-
Internally sloped slide out condensate pan conforms to ASHRAE 62 standards
-
High performance belt drive motor with variable pitch pulleys and quick adjust belt system
-
Permanently lubricated evaporator, condenser and gas heat inducer motors
-
Condenser motors are internally protected, totally enclosed with shaft down design
-
2 inch filter standard with slide out design
-
24 volt control system with resettable circuit breakers
-
Colored and labeled wiring
