Efficiency

  • .59 - .62 EF

Performance

  • FHR: 120 gallons for 75-gallon models and 104 gallons for 60-gallon models
  • Recovery rate is 69.7 to 75.8 for 75-gallon models and 50.5 to 55.6 for 60-gallon models at a 90 degree rise

Self-Diagnostic System

  • Electronic gas control for improved monitoring and service

Low Emissions

  • Eco-friendly burner, low NOx design

Features

  • Uses indoor air for combustion; blower exhausts the flue gases
  • Standard 110 VAC electrical connection
  • New whisper quiet blower
  • Offers larger capacities than the standard Power Vent

Guardian System™ & Sensor

  • Exclusive air/fuel shut-off device
  • Maintenance free – no filter to clean
  • Disables the heater in the presence of flammable vapor accumulation

Flexible Venting Options

  • Long venting lengths up to 100 equivalent feet
  • PVC, ABS, or CPVC vent pipe options
  • Vertical or horizontal termination

Longer Life

  • Rheem exclusive R-Tech (resistored) anode rod provides long-lasting tank protection

High Altitude Compliant

  • Models certified for applications up to 7,700 ft. above sea level

Plus…

  • Enhanced-flow brass drain valve
  • Temperature and pressure relief valve included
  • Low lead compliant
  • Durable silicon nitride ignitor (HSI)
  • EverKleen™ patented system fights sediment build-up
  • Standard replacement parts
 DESCRIPTION ENERGY INFO
PROFESSIONAL ACHIEVER PLUS SERIES HEAVY DUTY POWER VENT MODELS
TYPE GAL CAP. MODEL NUMBER ENERGY
FACTOR
NAT.
ENERGY STAR®
TALL
60 PRO+G60-55N RU62 PV 0.62 --
60  PRO+G60-50P RU62 PV  - --
75 PRO+G75-75N RU59 PV 0.59 --
75  PRO+G75-70P RU59 PV  - --
PRO+G75-76N RU PV

Specifications

  • Induced draft with the Guardian FVIR System
  • Flexible venting options up to 100 feet
  • 60 and 75 gallon tall and short capacities
  • Integrated self-diagnostic system control, thermostat and gas valve

  • US CSA (Star)
  • LEED Points = 1
  • AHRI
  • Energy Miser (Globe)

Documents

Professional Achiever Plus Heavy Duty Power Vent

Warranties

Limited Tank Warranty - 8 Years

Limited Parts Warranty - 8 Years

With ProtectionPlus™ the 8-year limited tank warranty becomes 12 Years
