Features & Benefits:

  • 80% residential Gas Furnace CSA certified
  • Two stages of operation to save energy and maintain optimal comfort level.
  • 3 way multi poise design UF / HZ
  • PlusOne™ Diagnostics — 7 Segment LED all units
  • PlusOne™ Ignition System – DSI for reliability and longevity
  • Heat exchanger is removable for improved serviceability. Aluminized steel construction provides maximum corrosion resistance and thermal fatigue reliability.
  • Solid doors provide quiet operation
  • Solid bottom
  • Insulated blower compartment
  • Low profile 34" cabinet ideal for space constrained installations
  • Blower shelf design – serviceable in all furnace orientations
  • Hemmed edges on cabinets and doors
  • 1/4 turn door knobs for tool less access
  • Integrated Control board features dip switches for easy system set up
  • QR code for quick access to product information from your smart phone or tablet

This furnace does not meet air district requirements of 14 ng/J NOx emissions limit, and thus is subject to a mitigation fee of up to $450. This furnace is not eligible for the Clean Air Furnace Rebate Program: www.CleanAirFurnaceRebate.com.

This furnace is to be installed for propane firing only in air districts requiring 14 ng/J NOx emission limits. Operating in natural gas mode is in violation of these Rules.

Specifications

  • Three way multi poise design
  • Constant Torque Motor
  • Input Rates 50-150 kBTU
  • Ruud-Exclusive PlusOne™ Ignition System
  • Industry-First PlusOne™ Diagnostics

Certifications

Documents

R802T (Upflow/Horizontal)

Warranties

Conditional Parts - 10 Years (Registration Required)

Heat Exchanger - Limited Lifetime
